Capacitance Meter, Professional LCR Meter Multimeter Digital Capacitor Tester Desktop Bridge 10Hz~100kHz Capacitor Check(ET4510)

Descriptions:A Digital LCR Bridge LCR meter is an electronic instrument used to measure the inductance (L), capacitance (C), and resistance (R) of components with high precision. Its primary functions include characterizing passive components, verifying specifications, and troubleshooting circuit issues. The device provides precise measurements at various frequencies, helping engineers and technicians ensure the performance and reliability of electronic circuits.Main technical indicators:ModelET4501ET4502ET4510Testing frequency10Hz ~10kHzcontinuously adjustable, 1Hz step10Hz ~20kHzcontinuously adjustable, 1Hz step10Hz ~100kHzcontinuously adjustable, 1Hz stepDisplay screen3.5" TFT LCD screenNumber of display digitsPrincipal parameter: 5 digitSecondary parameter: 5 digitMeasured parameter:Principal parameter: L/C/R/ZSecondary parameter: X/D/Q//ESRMeasurement rangeL:0.001µH-9999H,C:0.001pF-99.999mF,R:0.0001-99.99MBasic accuracy0.1%Measuring display speed2 time/s (slow), 4 times/s (medium), 8 time/s (fast)Internal bias0-1500mV adjustable, at a step of 1mV.Testing level0.1V~2V,continuously adjustable, 1mVstepSignal source output impedance30,100Calibration functionOpen circuit calibration, short circuit calibrationScreening functionThe limit range of screening can be set to -50%-+50%, and the fixed points are 1%, 5%, 10% and 20%.Comparator5 groups sorting,3 groups of qualified setting, one group of unqualified setting, one group of auxiliary setting

• High Accuracy: Delivers precise measurements of inductance, capacitance, and resistance
• Frequency Testing Range: Capable of testing components at different frequencies
• Clear Digital Interface: Provides a digital display for straightforward reading of results
• Automatic Measurement Adjustment: Automatically selects the appropriate range for ease of use
• Integrated Calibration: Incorporates calibration functions to ensure ongoing measurement reliability
