Reliable Reverse Circulation Drill Rig for Mining | Hydraulic RC Drilling Rig with Dust Collector for Cost-Effective, High-Speed Borehole Drilling and Geological Core Sampling

Product name: Reverse circulation drilling rig Condition:New Dimension(L*W*H):5800*2000*2300mm Weight:5800 KG Warranty:2 Years Core Components:Engine Key Selling Points:Low Maintenance Cost Drilling Diameter: 140mm Drilling Depth: 200m Walking Speed: 2.5km/h Working Pressure: 1.7-2.5 Mpa Drill pipe diameter:89-102mm Mobility:Tracked self-propelled Drilling method:Pneumatic Hammer Drilling Machinery Test Report:Provided Video outgoing-inspection:Provided

• Warm Tips: The prices listed are not final. This product offers a variety of customization styles and accessories, and prices vary depending on configuration. For more details, please via 𝐖/𝐀 +⑧⑥ ①⑤⓪ ③⑧③⑥ ①⑤⓪⑤ to leave a message before purchase.
• Every major function, including rig lifting, stabilizer extension, winch operation, and mobility, is powered by a fully hydraulic system. This design translates to smoother, more powerful control with significantly reduced physical effort required from operators, directly boosting overall job site productivity and operational precision.
• Built for demanding environments, this rig features heavy-duty components like wear-resistant roller slides in key movement areas. This construction philosophy ensures extended service life under continuous heavy loads, minimizes downtime for maintenance, and provides long-term reliability for your drilling investment.
• A key advantage of this RC drilling method is its independence from water during the drilling process. This makes it the ideal solution for operations in arid regions or locations where water access is logistically challenging or costly, greatly expanding its viable application areas.
• The rig's capability to utilize compressed air reverse circulation down-the-hole hammer drilling makes it adaptable to numerous ground conditions. This versatility eliminates the need for multiple specialized machines, allowing a single unit to tackle diverse projects from mineral exploration to deep hole water well drilling.
